รายละเอียด
+ 1/3”
+ EXview HAD CCD
+ 700TV Lines
+ Lens(f=2.8~12mm)
-------------------------------------------------------------------------------------
- Support OSD Menu. Motion detection. Private Area, SONY Effio-E DSP
- 1/3” EXview HAD CCD ||
- 700TV Lines
- Lens(f=2.8~12mm)
- Vari-focal Lens of Korean(len 2000,000 pixel)
- 0.06Lux/F1.2
- 30~40 meters
- IP65
SPECIFICATIONS
Model
|
CMR1600RS-E3
|
Menu control | Support OSD Menu, Motion detection,Private Area,SONY Effio-E DSP |
Image Sensor | 1/3" EXview HAD CCD II™ |
H.Resolution | 700TV Lines |
Lens | Lens(f=2.8~12mm) |
Type lens | Vari-focal Lens of korean(len 2000,000 pixel) |
Effective Pixel | PAL:768(H)*494(V),NTSC:752(H)*582(V) |
Min. Illumination | 0.06Lux/F1.2 |
IR Distance | 30~40 meters |
Dust&Water Resistance | IP65 |
Video Output | 1.0Vp-p Composite Output (75Ω / BNC) |
S/N Ratio | ≥52dB |
LED Wave length | 42 unit 850nm infrared LED |
Working Temperature | -20℃~+50℃ |
Working Humidity | ≤95% RH no dew |
Power Supply | DC12V(+/-10%), Max.1000mA |
Power Consumption | Max.1.2W |
Packing Dimension | 270*165*120mm |
Gross Weight | 0.86kgs |
Accessories | Buil in bracket |
